NC Helix Drill | Patent Pending | ||||
 |
 |
 |
||||
| Rough milling Drilling & Slotting |
 |
 |
 |
 |
||
| The expert to remove excess materials Principle and Benefit One tool performs multiple functions. It cuts a hole by helical interpolation; the serrated cutting edge makes cutting chip short and easily to be removed. |
 |
 |
 |
 |
||
 |
 |
Two types | ||||
 |
 |
Cylindrical Shank with helical groove is designed for CNC machines << without internal coolant supply. The design of helical groove takes away << the cutting chips while rotating. |
||||
| Screw-fit Tool Holder is applicable to fit into almost all extension bars in the market. << It has internal coolant through center, the cutting chips can be flushed out from hole together with the coolant. << |
||||||
 NC Helix Drill |
 |
|||
| Principle and Benefit The expert to remove excess materials - rough milling, drilling and slotting One tool performs multiple fuctions. It cuts a hole by helical interpolation; the serrated cutting edge makes cutting chip short and easily to be removed. |
 |
|||
 |
Lower Spindle Power Consumption Fast and Easy! * Thanks to the small cutting load of the serrated cutting edge and helical interpolation, low power consumption of the spindle is required. * Circular ramping milling, Maximum ramping angle is 20° |
 |
||
 |
|
 |
||
 |
Only six tools for drilling Ø13~Ø65 mm * The hole is cut by helical interpolation. Just one tool can machine different diameters and depth of holes. * Example: Ø11 NC Helix drill can drill Ø15 and Ø20, just programmed different circular radius I=2mm and I=4.5mm. |
|||
 |
||||
 |
||||
 |
Special geometry insert to cut different materials * Serrated cutting edge makes the cutting chips short and small, therefore easier to be removed. * For almost all kind of materials, excellant for soft and long cutting chip materials!, such as low carbon steel, stainless steel, Titanium and Inconel. * Eliminate swarf and virbration problems while drilling difficult cut materials or deeper hole. |
 |
||
 |
Two types of NC Helix drill for your options * Cylindrical Shank with helical groove is designed for CNC machines without internal coolant supply. The design of helical groove takes away the cutting chips while rotating. * Screw-fit Tool Holder is applicable to fit into almost all extension bars in the market. It has internal coolant through center, the cutting chips can be flushed out from hole together with the coolant. |
 |
||
 |
 |
 |
||
 |
 |
 |
 |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
Special geometry insert to cut different materials | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| * Serrated cutting edge makes the cutting chips short and small, therefore easier to be removed. * For almost all kind of materials, excellant for soft and long cutting chip materials!, such as low carbon steel, stainless steel, Titanium and Inconel. * Eliminate swarf and virbration problems while drilling difficult cut materials or deeper hole. |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| NC2032: Micro grain carbide insert, one insert has 2 cutting edges. |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
Two types of NC Helix drill for your options Cylindrical Shank and Screw Fit Cutter |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■ Cylindrical Shank Helical Chip-Removing Groove * Made from high alloy steel and hardened. * Special designed helical groove generates coolant chip-removing-stream. * The helical groove is designed to take swarf away from the cutting zone with the coolant. * Designed for the CNC machines with external coolant. |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
 |
 |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■ Screw Fit Cutter Centre Coolant * The holder is made from high alloy steel and hardened, standard screw-fit body adapts to almost any kind of the screw-fit tool holder or extension bar in the market. * Designed for the CNC machines with centre coolant. |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
 |
 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
 |
 |
 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
||||
| Example 1 | ||||
| Just one tool can cut holes from Ø20 to Ø30 mm |
||||
 |
||||
 |
||||
 |
||||
| Example 2 | ||||
| Making a hole Ø60x 27mm only by one tool Eliminates 2nd operation from before process |
||||
|
||||
 |
||||
| Example 3 | ||||
| BT30 Machine, Drilling hole Ø30, Drilling Depth 3.3xDc |
||||
 |
||||
|
||||
| Example 4 | ||||
| Reduce drilling cycle time. To make step hole Ø53.5 & Ø45 by one tool |
||||
 |
||||
| Example 5 | ||||
| Special geometry insert to cut different materials |
||||
 |
||||
 |
||||
 |
||||
 |
||||
|
|
||||
|
Example 6 |
||||
 |
||||
|
Example 7 |
||||
| Replace your end mill by NC Helix Drill. Make the impossible become possible! |
||||
 |
||||
 |
||||
|
Example 8 |
||||
| NC2032 insert grade is able to cut Titanium in different conditions |
||||
 |
||||
 |
 |
 |
 |
 |
 |
 |
|
Attention: |
| The NC Helix Drill is programing with "Helical interpolation" on CNC machine, the CNC controller must have 3-axis simultaneously motion function. |
 |
NC Helix Drill & Indexable Drill's Video link : https://youtu.be/Lj_FJwFCrxE
NC Helix Drill & Indexable Drill's Online Catalog link: http://online.fliphtml5.com/otaq/jprf/#p=1
For PDF catalog of NC Helix Drill & Indexable Drill please send a request to est@winwin.th.com
