Product Detail :
 |
||
|
Specification
| Code No. | M.T | A | B | B1 | C | C1 | D | E | L |
Center Runout (Max.) |
| NCW3-001 | No.3 | 64 | 15 | 36 | 91 | 10 | 36 | 43 | 170 | TIR0.005 |
| NCW4-001 | No.4 | 73 | 18 | 44 | 113.5 | 11 | 39 | 49 | 201.5 | |
| NCW5-001 | No.5 | 85 | 25 | 52 | 141.5 | 12 | 47 | 58 | 246.5 |
Features
- Designed for operating speeds (No.3 for 2500
, No.4 and No.5 for 2000).
- Designed to provide higher durability against thurst load than other models.
- Incorporates duplex thurst, thurst and needle bearings.
-The unique labyrinth mechanism (contactless) for protection against penetration of cutting oil has eliminated wear, friction and power loss, and minimized temperature rise of the machine, resulting in upgraded accuracy, increase service life and enhanced reliability.
- Especially recommended for use with our work-driving center.
Note: This model has a range of approx. 0.5mm longitudinal travel in no-load operations, but it offers a good performance without trouble.
